| CPU |
LGA1151 for 8th Gen Intel? Xeon? E / Core? i7/i5/i3 HC/QC/DC processors, up to 4.7GHz |
| 內存 |
4x DDR4-2666/ 2400 DIMM, Max. 64GB (supports ECC by CPU SKUs) |
| 芯片組 |
芯片為C246: Intel? C246 PCH 芯片為Q370：Intel? Q370 PCH |
| BIOS | AMI |
| 看門狗 | 256級 |
| SSD | mSATA , NVMe |
| 硬件監控 | Yes |
| 擴展槽 |
1x PCI-E(16x), 1x PCI-E(4x), 1x PCI-E(1x) 3x PCI-E, 1x MiniPCI-E, 1x M.2 (M-key, type:2280) 1x M.2 (E-key, type:2230) |
| VGA | CPU集成 |
| 顯存 | 共享 |
| 顯示接口 | 1x HDMI (2.0a), 1x DisplayPort (1.2), 1x DVI-D |
| 網絡芯片 |
LAN 1: Intel? I219LM GbE PHY LAN 2: Intel? I210AT GbE (MB995VF-C246), Intel? I211AT GbE (MB995VF) |
| 網卡接口 | 2x RJ-45 connectors |
| I/O 芯片 |
Fintek F81966D-I 4x RS232, 2x RS232/422/485 (用跳線選擇) |
| USB |
4x USB3.1 Gen2 (10Gbps) on board 5x USB3.1 Gen1 (5Gbps): -2 ports on board, 2 ports via box-headers -1 port via onboard vertical type connector 2x USB2.0 via pin-header |
| Serial ATA |
芯片為C246: 6x SATA III 芯片為Q370 4x SATA III |
| Audio | ALC888S 7.1 聲道 |
| Others |
Digital I/O (4-in/4-out), iAMT (11.6), TPM (2.0), RAID, iSMART (3.5), EuP/ErP |
| 尺寸 | 305mm x 244mm (12” x 9.6”) |
| 最大電流需求 |
Intel? Core? i7-8700 3.4GHz w/ 4x 4GB DDR4-2400 +12V: 5.56A +5V: 1.65A +5VSB: 0.25A +3.3V: 0.65A |
| 工作溫度 | 0°C~60°C (32°F~140°F) |
| 存儲溫度 | -20°C~80°C (-4°F~176°F) |
| 工作濕度 | 90% (無冷凝 @60°C) |
